Description
Product Description
The Ubiquiti RocketDish RD-5G30-LW is a high-performance lightweight parabolic antenna engineered for long-distance 5 GHz wireless bridging. Designed specifically for seamless integration with Ubiquiti Rocket™ radios, it delivers exceptional gain and directivity for stable, high-capacity point-to-point (PtP) links.
With its 30 dBi gain and narrow beamwidth, the RocketDish focuses RF energy efficiently, minimizing interference and maximizing signal strength over long distances. The lightweight (LW) design reduces wind load and simplifies installation, making it ideal for tower and pole deployments.
Built for durability, the antenna features industrial-grade materials and is optimized for outdoor environments, ensuring reliable performance even under harsh weather conditions.
Specifications (Verified & Accurate)
📡 Wireless & RF Performance
- Frequency Range: 5.1 – 5.9 GHz
- Antenna Gain: 30 dBi
- Beamwidth:
• Horizontal: ~5°
• Vertical: ~5° - Polarization: Dual Linear (requires Rocket radio)
- Cross-Pol Isolation: >30 dB
- Front-to-Back Ratio: >40 dB
- VSWR: ≤ 1.4:1
🔌 Hardware & Compatibility
- Connector Type: Rocket mount (no RF cable required)
- Compatibility: Designed for Ubiquiti Rocket M5 / Rocket 5AC radios
- Mounting: Heavy-duty pole mount kit included
- Integration: Plug-and-play integration with Rocket radios
🛠️ Physical & Environmental
- Dimensions: ~650 × 650 × 386 mm (25.6 × 25.6 × 15.2″)
- Weight: ~5.8 kg
- Wind Survivability: Up to 200 km/h (125 mph)
- Wind Loading: ~820 N @ 200 km/h
- Operating Temp: -40 °C to 70 °C (-40 °F to 158 °F)
- Outdoor Rating: Weather-resistant, UV-stabilized materials
🔧 Installation & Deployment
- Alignment: Precision alignment brackets for accurate aiming
- Deployment Type: Pole or tower mounting
- Design: Lightweight (LW) structure for reduced wind resistance
- Use Requirement: Requires compatible Rocket radio (not included)
Key Features
✔ 30 dBi high-gain antenna for ultra long-range wireless links
✔ Lightweight (LW) design for reduced wind load and easier installation
✔ Narrow beamwidth for improved interference rejection
✔ Seamless integration with Ubiquiti Rocket radios
✔ Dual-linear polarization for enhanced performance
✔ Rugged outdoor construction for harsh environments
✔ Ideal for high-capacity point-to-point deployments
Typical Use Cases
✔ Long-distance point-to-point wireless bridging
✔ ISP backhaul infrastructure
✔ High-capacity wireless links between towers
✔ Rural and remote connectivity deployments
✔ Backbone links for enterprise or campus networks
