Description

Product Description

The ZKTeco SpeedFace V5L is a next-generation hybrid biometric terminal designed for advanced access control and attendance management. It combines visible light facial recognition with fingerprint and palm recognition technologies, enabling fast, accurate, and completely contactless authentication.

The device supports multiple verification methods including face, fingerprint, palm, RFID card, password, and optional QR code authentication, making it highly flexible for modern security systems. Its advanced anti-spoofing algorithms effectively detect fake photos and videos, ensuring reliable identity verification.

Equipped with a high-resolution 5-inch touch display and a 2MP WDR binocular camera, the SpeedFace V5L delivers accurate recognition even in low-light environments. It also supports mask detection and touchless authentication, making it suitable for hygienic access control in public and high-traffic areas.

Powered by a Linux-based system with high-performance hardware, the device ensures stable operation and fast processing. It supports multiple communication protocols such as TCP/IP, RS485, Wiegand, and optional WiFi, allowing seamless integration with enterprise systems and software like ZKBio CVAccess and ZKBio Zlink.

Additionally, the SpeedFace V5L supports video intercom (SIP protocol) and ONVIF compatibility, enabling integration with surveillance systems and smart building infrastructure.

Key Features

• Multi-biometric authentication: Face, Fingerprint, Palm, RFID Card & Password
• Visible light facial recognition technology
• Advanced palm recognition (shape, print & vein)
• Anti-spoofing protection (photo & video detection)
• Touchless and mask detection support
• QR code authentication (optional)
• 5-inch HD touch display
• 2MP WDR camera with LED fill light
• High-speed verification (≤1 second)
• TCP/IP, RS485, Wiegand & optional WiFi
• Video intercom (SIP) & ONVIF compatibility
• Large user and transaction capacity

Technical Specifications

System

• Operating System: Linux
• CPU: Dual-core / Quad-core (model variant)
• RAM: 1GB
• ROM: 8GB

Display

• Screen: 5-inch IPS Color Touch Display (720 × 1280)

Camera

• 2MP WDR Binocular Camera with LED light

Capacity

• Face Capacity: 6,000
• Fingerprint Capacity: 6,000 (optional up to 10,000)
• Palm Capacity: 3,000
• Card Capacity: 10,000 (optional)
• Log Capacity: 200,000

Authentication Methods

• Face Recognition
• Fingerprint
• Palm Recognition
• RFID Card (125KHz / 13.56MHz optional)
• Password
• QR Code (optional)

Performance

• Face Recognition Speed: ≤ 1 second
• Palm Recognition Speed: ~0.35 sec
• FAR/FRR: Industry standard high accuracy

Communication

• TCP/IP
• RS485
• Wiegand Input/Output
• USB
• Optional WiFi

Access Control Functions

• Electric lock support
• Door sensor input
• Exit button
• Alarm output
• Auxiliary input

Video Intercom & Integration

• SIP Protocol support
• ONVIF compatibility
• ZKBio CVAccess / ZKBio Zlink support

Standard Functions

• ADMS
• Access levels & groups
• Anti-passback
• Record query
• Tamper switch alarm
• Multiple verification modes

Power

• DC 12V 3A

Environment

• Operating Temperature: -10°C to 45°C
• Humidity: 10% – 90% RH

Physical

• Dimensions: 202.9 × 91.9 × 21.5 mm
• Installation: Wall-mounted
• Weight: ~0.6 kg

Use Cases

• Corporate offices & enterprises
• Government & high-security facilities
• Hospitals & healthcare environments
• Industrial & factory sites
• Educational institutions
• Smart buildings & public access points
