Description
Key Features
✔ 8× Gigabit RJ45 Ports with auto‑sensing IEEE 802.3af/at PoE+ and configurable 24 V passive PoE for flexible device support.
✔ 2× 1 Gbps SFP Uplink Ports for fiber connectivity or long‑distance uplinks.
✔ 150 W Total PoE Power Budget to power multiple PoE devices simultaneously.
✔ 10 Gbps Non‑Blocking Throughput with 20 Gbps switching capacity for stable, high‑speed performance.
✔ Managed via UniFi Network Controller for centralized setup, monitoring, and network configuration.
✔ Fanless, Quiet Operation suitable for desktop or rack‑mounted deployment.
✔ Auto‑MDI/MDIX Support and store‑and‑forward switching for plug‑and‑play simplicity.
✔ Robust Protection with ESD/EMP safeguards (±24 kV).
Technical Specifications
| Specification | Details |
|---|---|
| Model | Ubiquiti UniFi US‑8‑150W |
| Ethernet Ports | 8 × 10/100/1000 Mbps RJ45 with PoE/PoE+ support |
| SFP Uplink Ports | 2 × 1 Gbps SFP |
| PoE Standards | IEEE 802.3af/at PoE+, Configurable 24 V Passive PoE |
| Total PoE Budget | Up to 150 W |
| Switching Capacity | 20 Gbps |
| Non‑Blocking Throughput | 10 Gbps |
| Forwarding Rate | ~14.88 Mpps |
| Management | UniFi Network Controller (software) |
| Power Supply | Internal 150 W AC/DC |
| ESD/EMP Protection | ±24 kV Air, ±24 kV Contact |
| Operating Temp. | –5 °C to 40 °C |
| Humidity | 5 %–95 % (non‑condensing) |
| Dimensions | 204 × 43 × 235 mm |
| Weight | ~1.7 kg |
Ideal Applications
The Ubiquiti US‑8‑150W is perfect for:
-
Small and medium business networks needing PoE power and centralized management.
-
Wireless access point deployments requiring reliable PoE+ power delivery.
-
IP surveillance systems with PoE cameras and fiber uplinks.
-
VoIP phone systems and other PoE‑enabled edge devices in office environments.
-
Home office or compact network setups benefiting from quiet fanless operation.
Trust & Performance Highlights
✔ Managed UniFi networking with advanced control and monitoring via software controller.
✔ Dual uplink flexibility with both copper and optical connectivity.
✔ High PoE power budget to support multiple high‑power PoE devices concurrently.
✔ Robust design with built‑in protection for reliable long‑term operation.
