Description
Product Description
The U7‑LR (UniFi 7 Long‑Range) access point from Ubiquiti is a next‑generation wireless solution built to deliver advanced Wi‑Fi 7 performance while covering larger areas with strong, stable connectivity. It supports the latest 802.11be standard — combining innovations like MU‑MIMO, OFDMA, and EHT160 bandwidth to improve throughput, lower latency, and efficiently handle multiple connected devices.
Featuring a sleek ceiling or wall mount design, the U7‑LR integrates easily into modern infrastructures such as offices, schools, retail spaces, and high‑density environments. With a 2.5 GbE PoE+ uplink port, it simplifies installation by combining power and data over a single cable. Centralized management and configuration are handled through the UniFi Network Controller or the UniFi mobile app for seamless deployment and control.
Specifications (Accurate & Verified)
Wireless Performance
- Wi‑Fi Standard: Wi‑Fi 7 (IEEE 802.11be), backward compatible with Wi‑Fi 6/5/4
- Bands: Dual‑band (2.4 GHz & 5 GHz)
- Maximum Throughput: ~4988 Mbps (4.9 Gbps) total
- 5 GHz: up to ~4300 Mbps
- 2.4 GHz: up to ~688 Mbps
- Spatial Streams: 5 streams (3×3 on 5 GHz + 2×2 on 2.4 GHz)
- MU‑MIMO & OFDMA: Yes — improved multi‑device efficiency
- Channel Bandwidth: HE/EHT 20/40/80/160 MHz
- Antenna Gain:
- 5 GHz: ~6 dBi
- 2.4 GHz: ~4 dBi
Hardware & Connectivity
- Ethernet:
- 1 × 2.5 GbE RJ45 (PoE+) for uplink and power
- Power:
- PoE+ (802.3at) compatible; PoE adapter recommended
- Mounting:
- Ceiling or wall mount (mounting kit included)
- Dimensions & Weight: ~Ø175.7 × 43 mm; ~448 g
Coverage & Capacity
- Recommended Coverage: ~160 m² (~1,750 ft²) — depends on environment and layout
- Client Capacity: 300+ concurrent clients supported
- Roaming: Fast roaming with UniFi controller
- Management: Centralized via UniFi Network Controller / App
- Security: WPA/WPA2/WPA3 support, guest network isolation
Key Features
✔ Next‑generation Wi‑Fi 7 support — ultra‑fast throughput and future‑ready capabilities
✔ Dual‑band long‑range performance with up to ~4.9 Gbps combined speed
✔ 5‑stream architecture for efficient multi‑device handling
✔ 2.5 GbE PoE+ uplink — simplifies installation and supports high‑speed backhaul
✔ Ceiling/wall mount design — clean deployment in indoor environments
✔ Centralized UniFi Network management — advanced configuration, monitoring, and updates
✔ Seamless roaming with controller‑based optimization
Use Cases
✔ Enterprise offices and meeting spaces
✔ Schools, libraries, and campuses
✔ High‑density network environments
✔ Retail and public venues
✔ Smart homes with multiple devices
