Product Description
The Ubiquiti Rocket Prism R5AC-Gen2 is an advanced 5 GHz airMAX® ac base station engineered for high-capacity point-to-multipoint (PtMP) deployments. Featuring Ubiquiti’s Prism™ active RF filtering technology, it delivers superior noise isolation and interference rejection, making it ideal for dense RF environments.
With integrated GPS synchronization, the Rocket Prism enables efficient frequency reuse and co-location of multiple radios, improving network scalability and performance. It is designed to work seamlessly with Ubiquiti airMAX® sector antennas and RocketDish antennas for flexible deployment scenarios.
Equipped with Gigabit Ethernet, dedicated management Wi-Fi, and AirOS® 8, the R5AC-Gen2 provides powerful tools for configuration, monitoring, and optimization—making it a preferred solution for WISPs and enterprise wireless networks.
Specifications (Verified & Accurate)
📡 Wireless & RF Performance
- Frequency: 5 GHz (5150 – 5875 MHz)
- Max Throughput: 500+ Mbps (airMAX® ac)
- airMAX Protocol: airMAX® ac
- Channel Sizes:
• PtMP Mode: 10/20/30/40 MHz
• PtP Mode: 10/20/30/40/50/60/80 MHz - Modulation: Up to 256-QAM
- GPS Sync: Yes (for co-location)
🔌 Hardware & Interfaces
- Networking: 1 × Gigabit Ethernet (RJ45) (PoE & data)
- RF Connectors: 2 × RP-SMA (for external antennas)
- Management Wi-Fi: Dedicated 2.4 GHz radio
- Power: 24 V, 0.5 A Passive PoE (included)
- Processor: Atheros MIPS 74Kc, 720 MHz
- Memory: 128 MB DDR2, 16 MB Flash
- LEDs: Power, Ethernet, GPS, and signal indicators
🛠️ Physical & Environmental
- Dimensions: ~230 × 132 × 48 mm
- Weight: ~830 g
- Operating Temp: -40 °C to 70 °C (-40 °F to 158 °F)
- Humidity: 5% – 95% non-condensing
- Mounting: Pole mount compatible
- Outdoor Rating: Weather-resistant enclosure
🔧 Software & Management
- AirOS® 8: Advanced RF analytics and performance tools
- Management: Web UI and mobile app setup (via management Wi-Fi)
- Features:
• Prism™ active RF filtering
• GPS synchronization for interference mitigation
• Spectrum analyzer and link diagnostics
• Real-time performance monitoring - Modes: Access Point / PtMP base station
Key Features
✔ Prism™ active RF filtering for superior interference rejection
✔ airMAX® ac technology for high throughput and efficiency
✔ GPS synchronization for high-density deployments
✔ Dedicated management Wi-Fi for easy setup
✔ Flexible antenna compatibility (sector and dish)
✔ Gigabit Ethernet with Passive PoE support
✔ Ideal for WISP and large-scale PtMP networks
Typical Use Cases
✔ Wireless ISP (WISP) base station deployments
✔ Point-to-multipoint outdoor networks
✔ High-interference environments requiring RF filtering
✔ Sector-based wireless distribution
✔ Scalable broadband infrastructure
