Description
2MP HD dome camera with clear, detailed video and reliable low-light performance. Compact, weather-resistant design ideal for indoor and outdoor surveillance with PoE and remote monitoring support.
Dahua IPC-HDW2230TP-AS-S2 2MP Dome Camera
MAIN FEATURES:
- 2MP 30M IR Night Vision Audio Eyeball Network Camera – 1080P
- 2MP, 1/2.7” CMOS image sensor, low illuminance, high image definition
- Outputs 2MP (1920 × 1080)@25/30 fps · H.265 codec, high compression ration, ultra-low bit rate
- Built-in IR LED, max IR distance: 30 m
- ROI, SMART H.264/H.265, flexible coding, applicable to various bandwidth and storage environments
- Rotation mode, DWDR, 3D DNR, HLC, BLC, digital watermarking, applicable to various monitoring scenes
- Intelligent detection: Intrusion, tripwire
- Abnormality detection: Motion detection, video tampering, no SD card, SD card full, SD card error, network disconnected, IP conflict, illegal access, voltage detection
- Supports max. 256 GB Micro SD card, built-in Mic
- 12V DC/PoE power support
- IP67 protection
Related products
-
Dahua DH‑HAC‑HDW1209CLQP‑A‑LED 2MP Dome Camera — The Dahua DH‑HAC‑HDW1209CLQP‑A‑LED is a versatile 2 MP full‑color HDCVI dome camera offering 1080p Full HD resolution at up to 30 fps with consistent color imaging day and night. It features built‑in LED illumination for clear low‑light performance up to ~20 m, a fixed 2.8 mm wide‑angle lens with broad field of view, and 4‑in‑1 switchable output (CVI/TVI/AHD/CVBS) for flexible DVR compatibility. With DWDR, BLC/HLC and 2D‑DNR enhancements and an IP67 weather‑proof housing, it’s ideal for both indoor and outdoor surveillance in homes, shops, and offices.
-
MAIN FEATURES:
- 4MP, 1/3” CMOS image sensor, low illuminance, high image definition
- Outputs 4MP (2560 × 1440)@25/30 fps, Max. supports 4MP (2688 × 1520) @ 20 fps
- H.265 coding, high compression ration, low bit rate
- Built-in IR LED, max IR distance: 30 m
- ROI, SMART H.264+/H.265+, flexible coding, applicable to various bandwidth and storage environments
- Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes
- Intelligent detection: Intrusion, tripwire
- Abnormality detection: Motion detection, video tampering,no SD card, SD card full, SD card error, network disconnected, IP conflict, illegal access, voltage detection
- Max. 256 GB SD card and built-in Mic
- 12V DC/POE power supply
- IP67 protection
-
- 5MP resolution (2880×1620)
- LED illuminator for improved low-light performance
- IP67 rating for dust and water resistance
- Same physical dimensions and design
- No audio capabilities (no built-in microphone or speaker)
- No PoE (Power over Ethernet) support
-
1. Image Sensor: 1/2.7″ CMOS
2. Pixel: 5 MP
3. Max Resolution: 2592 (H) × 1944 (V)
4. ROM: 128 MB
5. RAM: 256 MB
6. Scanning System: Progressive
7. Electronic Shutter Speed: Auto/Manual 1/3 s–1/100,000 s
8. Min. Illumination: 0.01 Lux@F1.6
9. S/N Ratio: ＞56 dB
10. Illumination Distance: 30 m (98.43 ft)
11. Illuminator On/Off Control: Auto/Manual
12. Illuminator Number: 1 (IR LED)
13. Pan/Tilt/Rotation Range: Horizonal: 0°–360°, Vertical: 0°–90°, Rotation: 0°–360°
14. Built-in Battery: Support SUPERCAP 0.08F
15. Lens Type: Fixed-focal
16. Lens Mount: M12
17. Focal Length: 2.8 mm; 3.6 mm
18. Max. Aperture: F1.6
19. Field of View: Horizontal: 84.0°; Vertical: 58.0°; Diagonal: 110.0°
20. Iris Control: Fixed
21. Close Focus Distance: 1.6 m; 0.9 m
22. DORI Distance: D: 56 m; O: 22.4 m; R: 11.2 m; I: 5.6 m
23. IVS: Tripwire; intrusion
24. Video Compression: H.265; H.264; H.264B; MJPEG
25. Smart Codec: Yes
26. Video Frame Rate: Main stream: 2592 × 1944 (1 fps-20 fps); Sub stream: 704 × 576 (1 fps-25 fps)
27. Stream Capability: 2 streams
28. Resolution: 2592×1944; 2688×1520; 3M; 2304×1296; 1080p; 1.3M; 720p; D1; VGA; CIF
29. Bit Rate Control: CBR/VBR
30. Video Bit Rate: H.264: 32 Kbps ~ 8192 Kbps; H.265: 12 Kbps ~ 8192 KbpsNetwork and Security
1. Network Port: RJ-45 (10/100 Base-T)
2. SDK and API: Yes
3. Network Protocol: HTTP; TCP; ARP; RTSP; RTP; UDP; RTCP; SMTP; FTP; DHCP; DNS; DDNS; PPPoE; IPv4/v6; QoS; UPnP; NTP; RTMP; Multicast; HTTPS; SFTP; 802.1x; ICMP; IGMP; Bonjour
4. Interoperability: ONVIF (Profile S/Profile G); CGI; P2P; Milestone; Genetec
5. User/Host: 20
6. Storage: Dahua Cloud; FTP; SFTP; Micro SD Card (support max. 256 GB); NAS
7. Browser: IE; Chrome; Firefox
8. Management Software: DMSS; DSS; Smart PSS
9. Mobile Client: Android; iOS
10. Image Setting: Gamma; Saturation; Sharpness; Contrast; Brightness
11. OSD Overlay: Time; channel; location
12. Record Mode: Manual record; video detection record; schedule record
13. Record priority: Manual > video detection > schedule
14. Default Support: one-click restore
15. User Management: Up to 20 Security
