Description

Product Description

The BAYNET BN-PG016-2S-300 is a professional-grade unmanaged Gigabit PoE switch designed to meet the demands of large surveillance systems and enterprise networks. It features 16 Gigabit PoE ports, along with 2 Gigabit RJ45 uplink ports and 2 SFP Gigabit fiber ports, offering flexible connectivity options for both standard and long-distance networking.

Compliant with IEEE 802.3af/at standards, the switch can supply power and data simultaneously over Ethernet cables to connected devices such as IP cameras, wireless access points, and VoIP phones. With a robust 300W total PoE power budget, it supports multiple high-power devices efficiently.

The inclusion of SFP fiber ports enables long-distance, interference-free data transmission, making it ideal for campus, industrial, and multi-building deployments. Its Gigabit switching architecture ensures smooth handling of high-bandwidth applications such as HD and 4K video streaming.

Equipped with intelligent PoE management and multiple protection mechanisms—including surge, overload, and short circuit protection—the BN-PG016-2S-300 ensures safe and stable operation. Its plug-and-play design allows for quick deployment without requiring configuration.

Specifications (Verified & Accurate)

📡 Ports & Interface

• PoE Ports: 16 × 10/100/1000 Mbps RJ45 (PoE)
• Uplink Ports: 2 × 10/100/1000 Mbps RJ45
• SFP Ports: 2 × Gigabit SFP Fiber Ports
• Total Ports: 20 Ports

⚡ PoE Features

• PoE Standard: IEEE 802.3af / IEEE 802.3at
• PoE Output: Up to 30W per port
• Total PoE Budget: 300W
• Power Pin Assignment: 1/2 (+), 3/6 (–)

🚀 Performance

• Switching Capacity: 36 Gbps
• Forwarding Rate: 26.78 Mpps
• MAC Address Table: 8K
• Transmission Mode: Store-and-Forward

🔌 Network Features

• Fiber Support: SFP ports for long-distance transmission
• Auto Negotiation & Auto MDI/MDIX: Supported
• Flow Control: IEEE 802.3x
• VLAN / Extend Mode: Supported (model dependent)
• Plug & Play: Yes (Unmanaged Switch)

🛡️ Protection & Reliability

• Lightning Protection: Up to 6KV
• Overload Protection: Yes
• Short Circuit Protection: Yes
• Surge Protection: Yes

⚙️ General

• Casing: Metal (Rack-mountable design)
• Installation: Rack Mount / Desktop
• Power Supply: AC 100–240V
• Operating Temperature: 0°C to 40°C
• Storage Temperature: –10°C to 70°C

Key Features

✔ 16 × Gigabit PoE ports for high-capacity deployments
✔ 2 × Gigabit uplink ports for network expansion
✔ 2 × SFP fiber ports for long-distance connectivity
✔ High 300W PoE power budget
✔ IEEE 802.3af/at compliant (up to 30W per port)
✔ Stable performance for HD & 4K video transmission
✔ Intelligent PoE protection (surge, overload, short circuit)
✔ Plug & play operation with no configuration required

Typical Use Cases

✔ Large-scale IP CCTV surveillance systems
✔ Enterprise and campus networks
✔ Multi-floor or multi-building installations
✔ Industrial and warehouse monitoring
✔ Fiber backbone network integration
