Product Description
The Dahua DHI‑NVR5864‑EI is a professional‑grade network video recorder designed for demanding surveillance systems with up to 64 IP camera channels. This NVR supports ultra‑high‑resolution cameras up to 32 MP, delivering detailed recording and monitoring for large commercial buildings, campuses, industrial sites, and extensive property coverage.
It features Smart H.265+ / H.265 / Smart H.264+ / H.264 / MJPEG encoding to optimize storage and bandwidth while maintaining superior video quality. With a maximum total bandwidth of 384 Mbps for incoming, recording, and outgoing streams, it ensures robust performance even with multiple high‑resolution cameras.
Built‑in AI analytics boosts detection accuracy and reduces false alarms. The unit includes face detection and recognition, perimeter protection, SMD Plus smart motion detection, and advanced camera‑level AI functions like metadata extraction, ANPR (license plate recognition), stereo analysis, people counting, and heat map analytics.
Storage is extensive with 8 SATA bays supporting up to 20 TB per drive, RAID configurations (0/1/5/6/10), and dedicated disk grouping for efficient data management. Dual HDMI and VGA outputs support up to 4K resolution display, while multi‑screen layouts enable flexible live viewing and playback across desktops or dedicated monitors.
Specifications (Verified & Accurate)
📹 System & Channels
- Channels: 64 IP camera inputs
- Max Camera Resolution: Up to 32 MP
- Max Bandwidth: 384 Mbps (incoming/recording/outgoing)
- Video Compression: Smart H.265+, H.265, Smart H.264+, H.264, MJPEG
🤖 AI & Smart Analytics
- AI by Recorder:
- Face detection & recognition (2 channels)
- Perimeter protection (4 channels)
- SMD Plus (8 channels)
- AI by Camera:
- Face detection & recognition
- Perimeter protection
- SMD Plus
- Video metadata (human/vehicle)
- ANPR (license plate)
- Stereo analysis
- Crowd distribution & people counting
- Vehicle density, heat map, PPE detection
- Smart object & sound detection
🛠️ Display & Playback
- Video Outputs:
- 2 × HDMI (up to 3840 × 2160 / 4K)
- 2 × VGA (1080p / 720p)
- Multi‑Screen Display: Main: 1/4/8/9/16/25/36/64
Sub: 1/4/8/9/16 - Playback: Instant, event, motion, tag, smart playback (face & motion)
💾 Storage & RAID
- HDD Bays: 8 × SATA (up to 20 TB each)
- RAID Support: 0 / 1 / 5 / 6 / 10
- Disk Group: Yes
📡 Network & Compatibility
- Network Ports: 2 × RJ45 (10/100/1000 Mbps)
- Protocols: HTTP, HTTPS, TCP/IP, IPv4/IPv6, RTSP, DHCP, DNS, DDNS, UPnP, FTP, SNMP, etc.
- Mobile Access: iOS & Android
- Third‑Party Support: ONVIF, CGI, SDK
🔊 Audio & Alarms
- Audio In: 1 × RCA
- Audio Out: 2 × RCA
- Alarm Input: 16 channels
- Alarm Output: 8 channels (1 × 12 V/1 A)
⚙️ General
- Operating System: Embedded Linux
- Power Supply: 100–240 VAC, 50–60 Hz
- Power Consumption: ≤ 13 W (without HDD)
- Dimensions: 439.9 × 457.9 × 89.0 mm
- Net Weight: ~6.4 kg
- Operating Temp.: –10 °C to +55 °C
Key Features
✔ Supports up to 64 IP camera channels with high‑resolution recording up to 32 MP
✔ Advanced AI analytics: face, perimeter, SMD, metadata & ANPR
✔ Smart H.265+ compression for efficient storage and bandwidth
✔ Dual HDMI & VGA outputs with flexible multi‑screen layouts
✔ 8 HDD bays with RAID support for large retention
✔ ONVIF & third‑party camera support
Typical Use Cases
✔ Large commercial or industrial surveillance systems
✔ Campus or multi‑building security networks
✔ High‑density IP CCTV networks requiring AI analytics
✔ Remote monitoring with mobile device access
✔ Long‑term recording with RAID redundancy
