Product Description
The USW-Lite-16-PoE SWITCH is part of Ubiquiti’s UniFi Lite series, built for compact enterprise and SMB networking. It provides Gigabit switching with limited PoE power support and fiber uplink capability, making it suitable for access points, IP cameras, and VoIP systems in small deployments.
It includes:
- 16 × 10/100/1000 Mbps Gigabit RJ45 ports
- 8 × PoE+ (802.3af/at) ports for powering network devices
- 2 × 1G SFP ports for fiber uplinks to core switches
- Managed via UniFi Network Controller for centralized configuration and monitoring
The switch is designed with a fanless, silent cooling system, making it suitable for office environments and continuous operation deployments.
Specifications (Verified & Accurate)
📡 Ports & Interface
- 16 × Gigabit RJ45 ports
- 8 × PoE+ ports (802.3af/at)
- 2 × 1G SFP uplink ports
- Total ports: 16 (plus PoE capability on 8 ports)
🚀 Performance
- Layer: Layer 2 Managed
- Switching Capacity: 32 Gbps
- Non-blocking throughput: 16 Gbps
- Forwarding rate: 24 Mpps
- MAC address table: 8K entries
- VLAN support: up to 1,000 VLANs
⚡ PoE Features
- PoE standard: IEEE 802.3af/at (PoE+)
- PoE ports: 8
- Max power per port: up to 30W
- Total PoE budget: 45W
🧠 Management & Features
- UniFi Network Controller / Cloud management
- VLAN (802.1Q)
- LACP link aggregation
- STP / RSTP
- IGMP Snooping
- 802.1X authentication
- Port isolation and traffic control
🛠️ Physical & Environment
- Form factor: Desktop / wall-mount
- Cooling: Fanless (silent operation)
- Power supply: Internal AC (100–240V)
- Operating temperature: approx. -15°C to 40°C
Key Features
✔ 16 Gigabit ports for high-speed LAN connectivity
✔ 8 PoE+ ports for APs, cameras, VoIP devices
✔ 2 SFP fiber uplinks for backbone connection
✔ UniFi Controller centralized management
✔ Fanless silent operation
✔ VLAN, QoS, and enterprise Layer 2 features
Typical Use Cases
✔ Small office / SMB networks
✔ IP camera surveillance systems
✔ WiFi access point deployments (UniFi ecosystem)
✔ VoIP phone systems
✔ Fiber uplink access-layer switching
